Brand Ubiquiti
Four-port GPON optical line terminal (OLT) designed to manage fiber internet service for up to 512 clients (128 per port).
Out of stock
Projects & bulk orders
For corporate projects we offer discovery, BOM and installation support for Ubiquiti Fiber OLT 4. Build your quote list and send it in one go.
My quote list (0) · Compare
Who is it for?
- ISPs and WISPs
- Fiber infrastructure projects
- Metro Ethernet providers
Use cases
- Fiber deployments and refresh projects
- Central management and cloud control (UniFi / UISP)
- Scalable enterprise WiFi and switching
- Technical support and bulk supply
Four-port GPON optical line terminal (OLT) designed to manage fiber internet service for up to 512 clients (128 per port).
Mekanik
- Dimensions
- 299.8 x 289 x 42.5 mm (11.8 x 11.4 x 1.7")
- Weight
- Without mounting brackets: 1.9 kg (4.3 lb)
With mount brackets: 2.1 kg (4.7 lb) - Enclosure material
- SGCC steel
Donanım
- Networking interface
- (4) GPON OLT SFP ports
(1) 10 Gbps SFP+ port - Management interface
- (1) Ethernet Out-of-Band
(1) RJ45 Serial Console port - Power method
- Universal input, 100—240V AC, 50/60 Hz / 25V DC
- Power supply
- AC/DC, internal, 56V DC
- Supported voltage range
- 100—240V AC / 16–25V DC
- Max. power consumption
- 35W (Excluding SFP modules)
- Button
- (1) Factory reset
- Ambient operating temperature
- -10 to 45° C (14 to 113° F)
- Ambient operating humidity
- 10 to 90% noncondensing
- Certifications
- CE, FCC, IC
LEDs
- Power
- (1) Blue/white
Blinking blue: reset to default
Steady blue: system is booting
Steady white: service is ready - GPON OLT SFP
- (4) White
Steady/blinking white: link/activity - SFP+
- (1) White/gren
White:10G
Green: 1G
Steady on after link is up; blinking while active - Ethernet
- (1) Green
Green: 1G
Steady on after link is up; blinking while active
Yazılım
- Mode
- OLT GPON Core and Layer 2 Ethernet switch
- VLAN
- 4062 VLANs supported
- Advanced QoS
- Support 8 priority queues per user port and traffic classification
- Concurrent clients
- 512 ONUs/ONTs registered
- Ubiquiti specific features
- UISP Mobile App
Fiber
- Operating wavelengthTXRX
1490 nm
1310 nm- Line code
- Scrambled NRZ
- Optical interface nominal bit rateDownstreamUpstream
2488.32 Mbit/s
1244.16 Mbit/s- Physical reach
- 20 km
- NDAA Compliant
- Yes
FAQ
- Ubiquiti Fiber OLT 4 nedir, ne işe yarar?
- Four-port GPON optical line terminal (OLT) designed to manage fiber internet service for up to 512 clients (128 per port).
- Ubiquiti Fiber OLT 4 kimler için uygundur?
- ISPs and WISPs, Fiber infrastructure projects, Metro Ethernet providers
- Ubiquiti Fiber OLT 4 fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: Out of stock
- Ubiquiti Fiber OLT 4 kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti Fiber OLT 4 model kodu (MPN) nedir?
- Resmi model: UF-OLT-4. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
