Brand Ubiquiti
Enterprise Audio/Video switch with (24) 10G PoE+++ ports and (4) 100G QSFP28 uplinks. Supports PTP timing, SMPTE ST 2110, SDVoE, and AES67 audio, with a high-precision OCXO clock and optional GPS grandmaster input (SMA) for deterministic media syncing.
In stock
Projects & bulk orders
For corporate projects we offer discovery, BOM and installation support for Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE. Build your quote list and send it in one go.
My quote list (0) · Compare
Who is it for?
- Data centers and server rooms
- Enterprise backbone networks
- IP camera and NVR infrastructure
- High PoE demand projects
Use cases
- Switch deployments and refresh projects
- Central management and cloud control (UniFi / UISP)
- Scalable enterprise WiFi and switching
- Technical support and bulk supply
- PoE IP camera power
- VLAN segmentation
Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE, Switching kategorisinde Layer 2 ve Layer 3 switching özellikleri sunan kurumsal PoE switch modelidir. Access point, IP kamera ve sunucu trafiğini tek noktadan yönetmenizi sağlar.
Ürün hakkında
Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE (EAV-XG-24-PoE (2150W)), yüksek performanslı switching için Switch segmentinde Türkiye'deki UniFi ve Ubiquiti projelerinde sık tercih edilen modellerdendir. UBNT Networks Mağaza üzerinden teknik özellikler, fiyat teklifi, toplu alım ve kurulum danışmanlığı talep edebilirsiniz.
Öne çıkan özellikler
- Boyutlar: 442.4 x 480 x 43.7 mm (17.4 x 18.9 x 1.7")
- 1 GbE RJ45: 1 (1G/100M/10M)
- 10 GbE RJ45: 24 (All PoE+++) (10G/5G/2.5G/1G/100M/10M) (10/100M half-duplex not supported)
- 100G QSFP28: 4 (100G/40G)
- Console: 1
- SMA: 1 (GPS input for Grandmaster clock mode)
Kimler için uygundur?
- Data centers and server rooms
- Enterprise backbone networks
- IP camera and NVR infrastructure
- High PoE demand projects
Kullanım senaryoları
Switch deployments and refresh projects; Central management and cloud control (UniFi / UISP); Scalable enterprise WiFi and switching.
Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE için detaylı teknik tablo, kutuda ne var bilgisi ve proje teklifi UBNT Networks Mağaza üzerinden sunulmaktadır.
Genel Bakış
- Dimensions
- 442.4 x 480 x 43.7 mm (17.4 x 18.9 x 1.7")
- 1 GbE RJ45
- 1 (1G/100M/10M)
- 10 GbE RJ45
- 24 (All PoE+++) (10G/5G/2.5G/1G/100M/10M) (10/100M half-duplex not supported)
- 100G QSFP28
- 4 (100G/40G)
- Console
- 1
- SMA
- 1 (GPS input for Grandmaster clock mode)
- Max. PoE Output
- Up to PoE+++
- Total PoE Availability
- 200-240V AC Shared Mode: 2,150W with (2) 1,200W modules 100-120V AC Shared Mode: 1,850W with (2) 1,200W modules 200-240V AC Redundant Mode: 1,050W with (2) 1,200W modules 100-120V AC Redundant Mode: 850W with (2) 1,200W modules
- Redundancy
- (2) Hot-Swappable PSUs (4) Hot-Swappable Fans
- Form Factor
- Rack Mount (1U, Full-Depth) (Requires a 4-post rack, or a center-mount bracket or cantilever shelf on 2-post racks for optimal support)
Performans
- Switching Capacity
- 1,280 Gbps
- Total Non-Blocking Throughput
- 640 Gbps
- Forwarding Rate
- 810 Mpps
- Supported VLANs
- 1,000
- MAC Address Table Size
- 32,000
- IPv4 Static Routes
- 512
- Packet Buffer Size
- 8 MB
- IPv4
- 256
- MAC
- 256
Layer 3 Features
Layer 2 Features
Donanım
- PoE+++
- 24
- PoE
- 15.4W
- PoE+
- 30W
- PoE++
- 60W
- PoE+++
- 90W
- Max. Power Consumption
- 150W (Excluding PoE Output) 2,400W (Including PoE Output)
- Power Method
- (2) Universal input, 100–240V AC, 50/60 Hz
- Power Input Method
- (2) AC input, Hot-swappable power modules
- Power Supply
- (2) Hot-swappable AC/DC 1,200W power modules
- Supported Voltage Range
- 100–240V AC
- Management
- Ethernet AR Serial Console
- Heat Dissipation
- 512 BTU/hr (Excluding PoE Output)
- Weight
- Without mounting brackets: 9.85 kg (21.7 lb) With mounting brackets: 9.95 kg (21.9 lb)
- Enclosure Material
- SGCC steel
- Mount Material
- SGCC steel
- Supported Rack Depth
- 482.6 mm (19") four-post racks Posts depths ranging from 650 to 1,000 mm (25.6–39.4”)
- LCM Display
- 1.3" touchscreen
- Fan Method
- (4) Hot-swappable fan modules (Fan modules operate with 3 + 1 redundancy)
- ESD Protection
- Air: ± 2KV, contact: ± 8KV
- Ambient Operating Temperature
- -5 to 40° C (23 to 104° F)
- Ambient Operating Humidity
- 10 to 90% noncondensing
- Certifications
- CE, FCC, IC
FAQ
- Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE nedir, ne işe yarar?
- Enterprise Audio/Video switch with (24) 10G PoE+++ ports and (4) 100G QSFP28 uplinks. Supports PTP timing, SMPTE ST 2110, SDVoE, and AES67 audio, with a high-precision OCXO clock and optional GPS grandmaster input (SMA) for deterministic media syncing.
- Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE kimler için uygundur?
- Data centers and server rooms, Enterprise backbone networks, IP camera and NVR infrastructure, High PoE demand projects
- Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: In stock
- Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti UniFi Enterprise Audio/Video XG 24 PoE model kodu (MPN) nedir?
- Resmi model: EAV-XG-24-PoE (2150W). Google Merchant ve teklif süreçlerinde bu kod kullanılır.
