العلامة Ubiquiti
5 GHz LTU client that establishes extremely long-distance wireless links with an LTU Rocket serving as its base station.
المشاريع والشراء بالجملة
لمشاريع الشركات: استكشاف وقائمة مواد ودعم تركيب لـ Ubiquiti LTU Extreme-Range. أنشئ قائمة العروض وأرسلها دفعة واحدة.
قائمة عروض الأسعار (0) · مقارنة
لمن يناسب؟
- آخر ميل
- شبكات الحرم
- فعاليات مؤقتة
حالات الاستخدام
- مشاريع airMAX والتحديث
- إدارة مركزية (UniFi / UISP)
- WiFi و switching قابل للتوسع
- دعم فني وتوريد بالجملة
5 GHz LTU client that establishes extremely long-distance wireless links with an LTU Rocket serving as its base station.
Mekanik
- Dimensions
- 747 x 525 x 347 mm (29.4 x 20.7 x 13.7")
- Weight
- 3.2 kg (7.1 lb)
- Enclosure material
- Aluminum alloy, UV-stabilized polycarbonate
- Mount material
- UV-stabilized polycarbonate
- Mount
- Integrated pole mount (included)
Pole compatibility: Ø35 to 60 mm (Ø1.4 to 2.4") - Wind loading
- 1100 N at 200 km/h (247.29 lbf at 125 mph)
- Weatherproofing
- IPX6
Donanım
- Networking interface
- (1) GbE RJ45 port
- Power method
- Passive PoE 2-pair (4, 5+; 7, 8-)
- Power supply
- 24V, 0.5A gigabit PoE adapter (Included)
- Supported voltage range
- 22—27V DC
- Max. power consumption
- 9W
- RF connections
- Internal
- LEDs
- Power/Ethernet
- Button
- Factory reset
- Ambient operating temperature
- -40 to 55° C (-40 to 131° F)
- Ambient operating humidity
- 5 to 95% non-condensing
- Certifications
- FCC, IC, CE
- NDAA Compliant
- Yes
Yazılım
- Modes
- PtMP CPE, PtP*
*1.5.1 and later 1.5.x series firmware. - Services
- SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog
- Utilities
- airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation
- Auto distance adjustment
- Yes
- Auto power adjustment
- Yes
- Network
- Bridge/Router* mode
*Router mode is available in PtMP CPE mode only. - Security
- Yes
- Statical reporting
- Yes
- Management interface
- Bluetooth management for easy setup over UISP App
WEB UI - Minimum software requirements
- Any modern web browser
iOS™ or Android™ based smartphone
Sistem
- Maximum throughput
- 900+ Mbps*
*FW version 2.3.0 and later. - Encryption
- WPA2-PSK (AES)
- Uplink/downlink ratio
- 25/75, 33/67, 50/50
RF
- Operating frequency*
- 5.15 to 5.95 GHz
*Depends on regulatory region. - Max. conducted TX power
- 25 dBm
- Channel bandwidth
- 10/20/30/40/50/60/80/100 MHz*
*FW version 2.3.0 and later. - Antenna gain
- 29 dBi
- Isolation
- 20 dB
- Beamwidth
- HPOL: 3 dB: 5.5°, 6 dB: 7.5°
VPOL: 3 dB: 5.5°, 6 dB: 7.5°
Elevation: 3 dB: 5.5°, 6 dB: 7.5° - Electrical downtilt
- 0°
الأسئلة الشائعة
- Ubiquiti LTU Extreme-Range nedir, ne işe yarar?
- 5 GHz LTU client that establishes extremely long-distance wireless links with an LTU Rocket serving as its base station.
- Ubiquiti LTU Extreme-Range kimler için uygundur?
- آخر ميل, شبكات الحرم, فعاليات مؤقتة
- Ubiquiti LTU Extreme-Range fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: متوفر
- Ubiquiti LTU Extreme-Range kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti LTU Extreme-Range model kodu (MPN) nedir?
- Resmi model: LTU-XR. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
