Бренд Ubiquiti
Ideal solution as a CPE in crowded RF environments such as urban areas.
В наличии
Проекты и опт
Для корпоративных проектов: обследование, спецификация и монтаж для Ubiquiti airMAX IsoStation M5. Соберите список и отправьте одним запросом.
Мой список запросов (0) · Сравнить
Для кого подходит?
- Последняя миля
- Кампусные сети
- Временные мероприятия
Сценарии использования
- Проекты и модернизация airMAX
- Централизованное управление (UniFi / UISP)
- Масштабируемый WiFi и switching
- Техподдержка и оптовые поставки
Ideal solution as a CPE in crowded RF environments such as urban areas.
Mekanik
- Dimensions
- With horn: 174 x 174 x 150 mm (6.9 x 6.9 x 5.9")
Without horn 131 x 131 x 65 mm (5.2 x 5.2 x 2.6") - Weight
- With horn: 726 g (1.6 lb)
408 g (0.90 lb) - Wind loading
- 36N @ 200 km/h (8.09lbf @ 125 mph)
- Wind survivability
- 200 km/h (125 mph)
- Mounting
- Pole-mount (Kit oncluded)
Donanım
- Networking interface
- (1) GbE RJ45 port
- Power method
- Passive PoE 2-pair (4, 5+; 7, 8 return)
- Power supply
- 24V, 0.5A gigabit PoE adapter (Included)
- Supported Voltage Range
- 22–27V DC
- Max. power consumption
- 6.5W
- Operating temperature
- -40 to 70 C (-40 to 158 F)
- Operating humidity
- 5 to 95% noncondensing
- Certifications
- CE, FCC, IC
- NDAA Compliant
- Yes
Sistem
- Gain
- 14 dBi
- Beamwidth
- 45° (Default Horn)
- Operating frequency
- Worldwide: 5150-5875 MHz
USA: U-NII-1: 5150-5250 MHz, U-NII-3: 5725-5850 MHz
Частые вопросы
- Ubiquiti airMAX IsoStation M5 nedir, ne işe yarar?
- Ideal solution as a CPE in crowded RF environments such as urban areas.
- Ubiquiti airMAX IsoStation M5 kimler için uygundur?
- Последняя миля, Кампусные сети, Временные мероприятия
- Ubiquiti airMAX IsoStation M5 fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: В наличии
- Ubiquiti airMAX IsoStation M5 kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti airMAX IsoStation M5 model kodu (MPN) nedir?
- Resmi model: IS-M5. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
