Brand Ubiquiti
Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.
In stock
Projects & bulk orders
For corporate projects we offer discovery, BOM and installation support for Ubiquiti UniFi U7 Pro XGS. Build your quote list and send it in one go.
My quote list (0) · Compare
Who is it for?
- Hotels and hospitality
- Cafés and restaurants
- Office and plaza management
- Education campuses
- Retail stores
Use cases
- Access Point deployments and refresh projects
- Central management and cloud control (UniFi / UISP)
- Scalable enterprise WiFi and switching
- Technical support and bulk supply
- Guest WiFi and hotspot
- Mesh and high-density areas
Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.
Access Point U7 Pro XGS
Özet
- Max. Client Count
- 500
- WiFi7
- WiFi 7
- Radio/Antenna
- 6 GHz Radio
Genel Bakış
- Dimensions
- ⌀215 x 32.5 mm (⌀8.5 x 1.3")
- WiFi Standard
- WiFi 7 (With 6 GHz support)
- Spatial Streams
- 8
- Coverage Area
- 160 m² (1,750 ft²)
- Max. Client Count
- 500+
- Uplink
- 10 GbE
- Mounting
- Ceiling, Wall (Lite Mount Included)
- Power Method
- PoE++
Performans
- 6 GHz
- 2 x 2 (DL/UL MU-MIMO)
- 5 GHz
- 4 x 4 (DL/UL MU-MIMO)
- 2.4 GHz
- 2 x 2 (DL/UL MU-MIMO)
- 6 GHz
- 5.8 Gbps (BW320)
- 5 GHz
- 8.6 Gbps (BW240)
- 2.4 GHz
- 688 Mbps (BW40)
- 6 GHz
- 6 dBi
- 5 GHz
- 6 dBi
- 2.4 GHz
- 4 dBi
- 6 GHz
- 24 dBm
- 5 GHz
- 29 dBm
- 2.4 GHz
- 23 dBm
- Max. BSSIDs
- 8 per Radio
- 802.11be (WiFi 7)
- 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320) 5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
- 802.11ax (WiFi 6)
- 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
- 802.11ac (WiFi 5)
- 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
- 802.11n
- 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
Özellikler
Donanım
- Max. Power Consumption
- 29W
- Supported Voltage Range
- 42.5–57V DC
- Networking Interface
- (1) 10 GbE RJ45 port
- Weight
- 800 g (1.8 lb)
- Management
- Ethernet
- Enclosure Material
- UV-stabilized polycarbonate, aluminum alloy
- Mount Material
- Stainless steel (SUS304), galvanized steel (SGCC)
- System
- White/Blue
- Channel Bandwidth
- HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
- Certifications
- CE, FCC, IC, Anatel: 05123-25-08356
- Operating Frequency
- US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8: 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz 5925 - 7125 MHz (For worldwide, it depends on the regulatory region)
- Ambient Operating Temperature
- -30 to 40° C (-22 to 104° F)
- Ambient Operating Humidity
- 5 to 95% noncondensing
Yazılım
- UniFi Network
- Version 9.0.114 and later (U7 Pro XGS - White) Version 9.1.120 and later (U7 Pro XGS - Black)
FAQ
- Ubiquiti UniFi U7 Pro XGS nedir, ne işe yarar?
- Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.
- Ubiquiti UniFi U7 Pro XGS kimler için uygundur?
- Hotels and hospitality, Cafés and restaurants, Office and plaza management, Education campuses, Retail stores
- Ubiquiti UniFi U7 Pro XGS fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: In stock
- Ubiquiti UniFi U7 Pro XGS kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti UniFi U7 Pro XGS model kodu (MPN) nedir?
- Resmi model: U7-Pro-XGS. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
