Brand Ubiquiti
Indoor/outdoor OSDP reader with NFC Card and Touch Pass support, compatible with the UniFi Retrofit Hub using existing cabling.
In stock
Projects & bulk orders
For corporate projects we offer discovery, BOM and installation support for Ubiquiti UniFi Retrofit Reader. Build your quote list and send it in one go.
My quote list (0) · Compare
Who is it for?
- Office and building access control
- Property management
- Manufacturing sites
Use cases
- Door Access deployments and refresh projects
- Central management and cloud control (UniFi / UISP)
- Scalable enterprise WiFi and switching
- Technical support and bulk supply
Indoor/outdoor OSDP reader with NFC Card and Touch Pass support, compatible with the UniFi Retrofit Hub using existing cabling.
Access Retrofit Reader
Özet
- Apple
- Touch Pass
- NFC
- NFC
- Weatherproof
- Outdoor Exposed
Genel Bakış
- Dimensions
- 117 x 45 x 13.3 mm (4.6 x 1.8 x 0.5")
- Weatherproofing
- IP55
Mechanical
- Weight
- 82 g (2.9 oz)
- Enclosure Material
- Polycarbonate, aluminum alloy
- Mount Material
- Stainless steel
- Mounting
- Wall, gang-box mount (Included) Junction box (Optional)
Donanım
- Indoor and Outdoor Use
- Yes
- Connectivity
- RS-485 BLE 4.1 NFC
- Security
- OSDP v2
- Power Method
- DC 12V
- Max. Power Consumption
- 2.5W
- Supported Voltage Range
- 12V DC
- ESD/EMP Protection
- Air: ± 15kV, contact: ± 8kV
- Speaker
- ((1) 0.7W)
- LEDs
- R/G/B/W Learn More
- Button
- (1) Factory reset
- NFC Frequency
- 13.56 MHz
- NFC Read Range
- < 30 mm (1.18'')
- NFC Technology
- ISO 14443A, 14443B, 15693 NFC Tag 1,2,3,4,5 MIFARE Classic MIFARE Plus MIFARE Ultralight MIFARE DESFire
- Certifications
- CE, FCC, IC
- Ambient Operating Temperature
- -30 to 50° C (-22 to 122° F)
- Ambient Operating Humidity
- 5 to 90% noncondensing
Yazılım
- Management Application
- Access
- Software Information
- The software version can be checked at https://unifi.ui.com
FAQ
- Ubiquiti UniFi Retrofit Reader nedir, ne işe yarar?
- Indoor/outdoor OSDP reader with NFC Card and Touch Pass support, compatible with the UniFi Retrofit Hub using existing cabling.
- Ubiquiti UniFi Retrofit Reader kimler için uygundur?
- Office and building access control, Property management, Manufacturing sites
- Ubiquiti UniFi Retrofit Reader fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: In stock
- Ubiquiti UniFi Retrofit Reader kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti UniFi Retrofit Reader model kodu (MPN) nedir?
- Resmi model: UA-Retrofit-Reader. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
