Marka Ubiquiti
220W (27V) PoE switch with (24) GbE RJ45 ports, including (16) with 27V passive PoE, and (4) 10G SFP+ ports.
Fiyat
Fiyat ve stok için sorunuz
Stokta
Proje & toplu alım
Kurumsal projelerde Ubiquiti UISP Switch Pro için keşif, BOM ve kurulum desteği sunuyoruz. Sepet yerine teklif listenizi oluşturup tek seferde gönderin.
Teklif listem (0 ürün) · Karşılaştır
Kimler için uygun?
- Veri merkezi ve sunucu odaları
- Kurumsal omurga ağları
- IP kamera ve NVR altyapıları
- Yüksek PoE ihtiyacı olan projeler
Kullanım alanları
- Switch kurulumları ve yenileme projeleri
- Merkezi yönetim ve bulut kontrol (UniFi / UISP)
- Ölçeklenebilir kurumsal WiFi ve switching
- Teknik destek ve toplu alım tedariki
- PoE IP kamera beslemesi
- VLAN segmentasyonu






220W (27V) PoE switch with (24) GbE RJ45 ports, including (16) with 27V passive PoE, and (4) 10G SFP+ ports.
Mekanik
- Boyutlar
- 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7")
- Ağırlık
- 4 kg (8.8 lb)
- Enclosure materials
- SGCC steel, polycarbonate/acrylonitrile butadiene styrene
Donanım
- Networking interface
- (24) GbE RJ45 LAN ports
(4) 1/10G SFP+ ports - Management interface
- Ethernet In-band
Bluetooth - Total non-blocking throughput
- 64 Gbps
- Switching capacity
- 128 Gbps
- Forwarding rate
- 95.23 Mpps
- Power method
- (1) Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz
(1) Power TransPort DC input 27V DC, 9.3A - Power supply
- AC/DC, Internal, 250W
- Supported voltage range
- 100—240V AC
- Max. power consumption
- 30W (Excluding PoE output)
- ESD/EMP protection
- Air: ± 15 kV, contact: ± 8 kV
- LCM display
- (1) 1.3" touchscreen
- Ambient operating temperature
- -10 to 50° C (14 to 122° F)
- Ambient operating humidity
- 5 to 95% noncondensing
- Sertifikalar
- CE, FCC, IC
PoE
- PoE interface
- (16) 27V passive PoE: 2-pair (Pins 4, 5+/7, 8-) or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16
- Total available PoE
- 220W
- Max. passive PoE wattage per port
- 30W/27V DC
- Passive PoE voltage range
- 27V DC
LEDs
- RJ45 data ports
- PoE
Speed/link/activity - SFP+ data ports
- Speed/link/activity
Yazılım
- Management application
- UISP: Version 1.5.7 and later
- NDAA Compliant
- Yes
Sık sorulan sorular
- Ubiquiti UISP Switch Pro nedir, ne işe yarar?
- 220W (27V) PoE switch with (24) GbE RJ45 ports, including (16) with 27V passive PoE, and (4) 10G SFP+ ports.
- Ubiquiti UISP Switch Pro kimler için uygundur?
- Veri merkezi ve sunucu odaları, Kurumsal omurga ağları, IP kamera ve NVR altyapıları, Yüksek PoE ihtiyacı olan projeler
- Ubiquiti UISP Switch Pro fiyatı ve stok durumu nedir?
- Proje bazlı teklif için iletişime geçin. Stok: Stokta
- Ubiquiti UISP Switch Pro kurulum ve proje desteği var mı?
- UBNT Networks Mağaza üzerinden toplu alım, kurulum danışmanlığı ve teknik destek talep edebilirsiniz.
- Ubiquiti UISP Switch Pro model kodu (MPN) nedir?
- Resmi model: UISP-S-Pro. Google Merchant ve teklif süreçlerinde bu kod kullanılır.
Toplu alım & proje
Ubiquiti UISP Switch Pro için kurumsal fiyat, stok ve kurulum desteği alın.
